Type passive 2-way full range
Frequency Response(Preset) 65Hz-18kHz(±3dB)
Horizontal 80°
Vertical 50°
Drivers LF:1×10"(Ferrite)
HF:1×1.75"(Ferrite)
Handling Power (AES) LF:250W
HF:60W
Maximum Peak SPL 128dB/1m
Nominal Impedance LF:8Ω / HF:8Ω
Connections 2 x NL4 SpeakOn
Pin Connections NL4=LF:+1-1
Width 307mm
Height 500mm
Depth 350mm
Weight 17kg / 37.4lb
Rigging and Handling
Handle 2 handles
Threaded 17x M8 threaded insert
Pole socket 1x 35mm Pole socket
Physical Data
Material Baltic Birch Plywood
Finish Dark Grey/Black
Front Polyester powder-coated steel grill
Rigging Steel
Protection rating IP45
QR10_SYSTEM_CAD_FILES Download
