| Type | passive 2-way full range |
| Frequency Response(Preset) | 60Hz-18kHz(±3dB) |
| Horizontal | 90° |
| Vertical | 40° |
| Drivers | LF：1×12"（Ferrite） |
| HF：1×1.75"（Ferrite） | |
| Handling Power (AES) | LF：250W |
| HF：60W | |
| Maximum Peak SPL | 132dB/1m |
| Nominal Impedance | LF:8Ω / HF:8Ω |
| Connections | 2 x NL4 SpeakOn |
| Pin Connections | NL4=LF:+1-1 |
| Width | 360mm |
| Height | 600mm |
| Depth | 380mm |
| Weight | 21kg/46.2lb |
| Rigging and Handling | |
| Handle | 2 handles |
| Threaded | 17x M8 threaded insert |
| Pole socket | 2x 35mm Pole socket |
| Physical Data | |
| Material | Baltic Birch Plywood |
| Finish | Dark grey/Black |
| Front | Polyester powder-coated steel grill |
| Rigging | Steel |
| Protection rating | IP45 |
