| Type | Subwoofer |
| Frequency Response(Preset) | 40Hz - 200Hz |
| Amplifier Recommend | VDA14 / VDA12 |
| Frequency Response（Preset） | [AngelLow] |
| Horizontal | 360° |
| Drivers | LF：2×12" 75mm Voice Coil Neodymium |
| Handling Power (RMS) | LF:1000W |
| Maximum Peak SPL | 137dB/1m |
| Nominal Impedance | LF：4Ω |
| Connectors | 1 x NL4 SpeakOn |
| Pin Connectors | IN = MF/ HF +2-2 |
| IN = MF/ HF +2-2 | |
| Height Front | 800mm |
| Height Back | 800mm |
| Width | 350mm |
| Depth | 400mm |
| Weight | 32kg / 70.5lbs |
| Rigging and Handling | |
| Handle | 2 ergonomic handles |
| Threaded | 4x M6 threaded insert |
| Pole socket | 1x 35mm Pole socket |
| Physical Data | |
| Material | Baltic Birch Plywood |
| Finish | Dark Grey |
| Front | Polyester powder-coated steel grill |
| Protection rating | IP55 |
 |
AngelLow-Base | Suitable for AngelLow enclosures，Protect enclosures |
 |
AngelLow Touring Flight Case | Accommodate 1 AngelLow Dimensions（W x H x D）：920 x 576 x 393mm |
 |
VDA14-Rack1 | 3U rack mounted with 1 VDA14 amplifiers, and 1 SCN Signal panel |
 |
VDA12 | 16Ω：4 x 600W RMS 8Ω：4 x 1200W RMS 4Ω/2.7Ω：4 x 2000W RMS 32-bit 96kHz sampling rate 4 x 4 matrix architecture 2x20 LCD Display、1 x RJ45 Network 100 V - 240 V ~ ±10%，50-60 Hz |
 |
4-Pin 4*4㎡ NL4 Speaker Cables | 1、4Pin-NL4-5（5meter） 3、4Pin-NL4-10（10meter） 3、4Pin-NL4-15（15meter） 4、4Pin-NL4-25（25meter） |
