Type | Subwoofer |
Amplifier Recommend | VDA18 / VDA14 / VDA12 / C15 |
Frequency Response(Preset) | 30Hz [Voe_100/C] [Voe_125/C] Preset |
Horizontal | 360° |
Drivers | LF:1×18" 100mm Voice Coil Ferrite |
Handling Power(RMS) | LF:600W |
Maximum Peak SPL | 137dB/1m |
Nominal Impedance | LF:8Ω |
Connections | 2 x NL4 SpeakOn |
Pin Connections | NL4=LF:+1-1 |
Dimensions(W x H x D) | 700 x 550 x700mm |
Weight | 46kg / 101.4lbs |
Rigging and Handling | |
Handle | 4 ergonomic handles |
Pole socket | N/C |
stand bar | 4x 10mm*38mm(H*⌀) |
Physical Data | |
Material | Baltic Birch Plywood |
Finish | Dark Grey |
Front | Polyester powder-coated steel grill |
Protection rating | IP55 |
