Type Passive 2-way Coaxial Enclosure
Frequency Response(Preset) 50Hz-20kHz
Horizontal 40°
Vertical 60°
Monitor Angle 55° / 35° (1)
0°(2)
Drivers LF:1×15" 75mm Voice Coil Neodymium
HF:1×3" 75mm Voice Coil Neodymium
Handling Power (RMS) LF:400W
HF:80W
Maximum Peak SPL 138dB/1m
Nominal Impedance LF:8Ω / HF:8Ω
Connections 2 x NL4 SpeakOn
Pin Connections NL4=LF:+1-1
Width 430mm
Height 600mm
Depth 350mm
Weight 21kg / 46.3lbs
Rigging and Handling
Handle 2 handles
Threaded 13x M8 threaded insert
Pole socket 2x 35mm Pole socket
stand bar 4x 10mm*38mm(H*⌀)
Physical Data
Material Baltic Birch Plywood
Finish Dark grey
Front Polyester powder-coated steel grill
Rigging Steel
Protection rating IP55
M15-UL Suitable for M15 enclosures
M15-ULi Suitable for M15 enclosures
Lighting Hook Suitable for connecting UL/ULi hangers
Eyebolt M8*30 lifting ring, used for connecting with buckle ring
M15 Touring Flight Case Accommodate 2 M15 Dimensions(W x H x D):845 x 810 x 490mm
M15-Cover 1 M15
VDA18-Rack1 3U rack mounted with 1 VDA18 amplifiers, and 1 SCN Signal panel
VDA14-Rack1 3U rack mounted with 1 VDA14 amplifiers, and 1 SCN Signal panel
2-Pin 2*4㎡ NL4 Speaker Cables 1、2Pin-NL4-5(5meter) 3、2Pin-NL4-10(10meter) 3、2Pin-NL4-15(15meter) 4、2Pin-NL4-25(25meter)
